Vertiv Liebert GXT5 UPS 2000VA/1800W 120V Online Rack Tower Energy Star
Vertiv Liebert GXT5 UPS 2000VA/1800W 120V Online Rack Tower Energy Star
Low stock: 5 left
Couldn't load pickup availability
Free shipping across the continental US & free returns
Description
Vertiv Liebert GXT5 UPS - 2000VA/1800W 120V | Online Rack Tower Energy Star
This is a Double Conversion Online UPS from the Vertiv Liebert GXT series. The Vertiv Liebert GXT5 UPS with 2000VA/1800W capacity provides online double-conversion power protection for IT infrastructure and mission-critical equipment. It supports 110/115/120/125V AC environments with scalable runtime via external battery cabinets and includes hardware for rack or tower installation.
Key Features
- Online double-conversion technology protects against outages and power disturbances without drawing on battery power during normal operation.
- Hot-swappable batteries and included rack mounting hardware kit plus tower base for flexible installation.
- ENERGY STAR 2.0 with leading normal-mode efficiency and Eco-mode option.
- Color LCD status indicators and multiple ports including USB HID compliant, serial, and EPO.
- Supports matching external battery cabinets for extended runtime during outages.
- Pure sine wave output with user-selectable voltages of 110/115/120VAC plus or minus 3 percent.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Vertiv Corp |
| Brand Name | Vertiv Liebert |
| Product Series | GXT |
| Product Name | GXT5 2000VA 120V UPS |
| Manufacturer Part Number | GXT5-2000LVRT2UXL |
| UPC | 767041026344 |
| Product Type | Double Conversion Online UPS |
| Load Capacity VA | 2000 VA |
| Load Capacity Watt | 1800 W |
| Input Voltage | 120 V AC |
| Input Voltage Range | 60 V AC - 150 V AC |
| Input Current | 16 A |
| Output Voltage | 120 V AC |
| Output Current | 16.70 A |
| Input Frequency | 70 Hz |
| Waveform Type | Pure Sine Wave |
| Plug Connector Type | NEMA L5-20P |
| Receptacle Type | NEMA 5-15/20R, NEMA L5-20R |
| Receptacle Detail | 6 x NEMA 5-15/20R, 1 x NEMA L5-20R |
| Cord Length | 10 ft |
| Transfer Time | 0 ns |
| Phase | Single Phase |
| Emergency Power OFF | Yes |
| Circuit Breaker | Yes |
| Application Usage | IT Equipment, Mission Critical Equipment |
| Number of Batteries | 3 |
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Battery Characteristics | Valve-regulated, Non-spillable |
| Backup Run Time Full Load | 3 Minute |
| Backup Run Time Half Load | 9 Minute |
| Number of External Battery Cabinets | 1 |
| Backup Run Time With External Battery Cabinet Full Load | 17 Minute |
| Backup Run Time With External Battery Cabinet Half Load | 42 Minute |
| Battery Life | 5 Year |
| Typical Battery Recharge Time | 3 Hour |
| Hot Pluggable | Yes |
| Hot Swappable | Yes |
| Status Indicators | Color LCD |
| Serial Port | Yes |
| EPO Port | Yes |
| USB HID Compliant Port | Yes |
| Maximum Operating Temperature | 104°F (40°C) |
| Storage Temperature | -4°F (-20°C) - 140°F (60°C) |
| Maximum Operating Elevation | 9842.52 ft |
| Maximum Storage Elevation | 49212.60 ft |
| Environmental Sensors | Leak Detection Sensor, Temperature Sensor, Humidity Sensor |
| Product Color | Black |
| Color Family | Black |
| Height | 3.4" |
| Width | 16.9" |
| Depth | 18.5" |
| Rack Height | 2U |
| Form Factor | Rack/Tower |
| Weight Approximate | 47.50 lb |
| Package Contents | GXT5 2000VA 120V UPS, 4 Post Rack Mounting, Tower Stand, USB Cable, User Guide, Safety Instruction Manual |
| Software Included | Free Download - Power Insight 2.2 |
| Certifications Standards | UL1778 4th Ed., FCC Part 15 Class A, ANSI C62.41 Cat. B, ISTA 1A |
| Energy Star | Yes |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | RoHS, REACH, WEEE, RoHS 2 |
| Assembly Required | No |
Package Contents
GXT5 2000VA 120V UPS, 4 Post Rack Mounting, Tower Stand, USB Cable, User Guide, Safety Instruction Manual.
Vertiv Liebert GXT5 UPS - 2000VA/1800W 120V | Online Rack Tower Energy Star
Brand: Liebert
Type: Double Conversion Online UPS
Output Voltage Rating (AC): 120 V
MPN: GXT5-2000LVRT2UXL
Mounting Style: Rack Mount
Nominal Voltage Rating (AC): 120 V
Color: Black
Features: Hot Swappable
Number of Batteries: 3
Maximum Operating Temperature: 40 °C (104 °F)
Country of Origin: China
Nominal Current Rating: 16 A
UPC: 767041026344
