Description
Vertiv Avocent AV3108 8-Port KVM Over IP Switch (AV3108-400)
This is a KVM Switchbox manufactured by Vertiv Corp under the Vertiv AVOCENT brand. The Vertiv Avocent Autoview 3000 (AV3000) KVM over IP Switches provide local and remote management and control of up to 16 servers from a single console. Supporting up to two local users and one remote user, this series of rackmount KVM switches is flexible, secure and easy to use. The Vertiv Avocent AV3000 KVM over IP Switches deliver enterprise-class performance at a small business price. The series features virtual media for enabling out-of-band file transfers and OS patch deployments, as well as support for two-factor authentication using smart cards or Common Access Cards (CAC) readers. Session sharing allows for diagnostic or multi-user viewing from anywhere in the world. These solutions also include local USB peripheral support, support LDAP user authentication, and AES encryption.
Key Features of Vertiv Avocent AV3108 KVM Switchbox
- 8 Computer Ports – Supports connection to 8 servers with local and remote access capabilities.
- Virtual Media Support – Enables out-of-band file transfers and OS patch deployments.
- Two-Factor Authentication – Compatible with smart cards or Common Access Cards (CAC) readers.
- Session Sharing – Allows diagnostic or multi-user viewing from remote locations.
- AES Encryption – Secures data transmission with LDAP user authentication support.
- Local USB Peripheral Support – Provides direct USB connectivity at the console.
- High Video Resolution – Delivers up to 1920 x 1080 maximum video resolution.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Vertiv Corp |
| Brand Name | Vertiv AVOCENT |
| Product Line | AutoView |
| Product Series | AV 3000 |
| Product Model | AV3108 |
| Manufacturer Item Number | AV3108-400 |
| UPC | 636430089294 |
| Product Type | KVM Switchbox |
| Number of Computers Supported | 8 |
| Number of Local Users Supported | 1 |
| Number of Remote Users Supported | 1 |
| Maximum Operating Distance | 98.43 ft |
| IP Rating | IP52 |
| Maximum Video Resolution | 1920 x 1080 |
| Number of Network (RJ-45) Ports | 11 |
| Number of USB Ports | 4 |
| Number of VGA Ports | 1 |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Input Current | 5 A |
| Input Voltage | 110 V AC, 220 V AC |
| Input Voltage Range | 100V AC to 240V AC |
| Frequency | 50 Hz, 60 Hz |
| Plug/Connector Type | C14 |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.7" |
| Width | 17" |
| Depth | 6.5" |
| Weight (Approximate) | 4.19 lb |
| Packaged Quantity | 1 |
| Country of Origin | United States |
Brand: Avocent
Type: KVM Switchbox
Color: Black
Compatible Brand: Vertiv AVOCENT
Compatible Model: AV3108
MPN: AV3108-400
Country of Origin: United States
Connection Split/Duplication: 1:8
Item Height: 1.7"
Item Length: 6.5"
Item Width: 17"
UPC: 636430089294
