StarTech.com PEX1394B3 3-Port Mini PCIe FireWire 2x800 1x400 Card
This is a StarTech.com 3 Port 2b 1a 1394 PCI Express FireWire Card, model PEX1394B3, a PCI Express to FireWire-800/FireWire-400 adapter designed for adding external FireWire connectivity to very small form factor or embedded systems. The PCIe FireWire card provides two FireWire-800 ports and one FireWire-400 port, supporting data transfer speeds up to 800 Mbps for external FireWire storage devices. UPC: 065030825139. It uses the Mini PCI Express (Mini Card) form factor for Mini-ITX or custom embedded solutions where full-sized cards do not fit. Backed by StarTech.com 2-year warranty and free lifetime technical support.
Key Features of StarTech.com PEX1394B3 FireWire Adapter
- 3-Port Configuration – Two FireWire-800 (IEEE 1394b) ports at 800 Mbps and one FireWire-400 (IEEE 1394a) port at 400 Mbps for versatile connectivity.
- Mini PCI Express Form Factor – Compact plug-in card ideal for small form factor systems like Mini-ITX or embedded PCs.
- PCI Express 1.1 x1 Host Interface – Ensures reliable high-speed performance in compatible PCIe slots.
- Broad OS Compatibility – Supports Windows 2000 to 11, Windows Server 2003 to 2019, macOS 10.6 to 13.0 (Ventura), and Linux 3.5.x LTS and up across PC, Mac, and Linux platforms.
- TAA Compliant – Meets Trade Agreements Act standards; made in Taiwan.
- Environmentally Friendly – Designed with sustainability in mind.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | StarTech.com |
| Brand Name | StarTech.com |
| Manufacturer Part Number | PEX1394B3 |
| Product Name | 3 Port 2b 1a 1394 PCI Express FireWire Card Adapter |
| Product Type | FireWire Adapter |
| UPC | 065030825139 |
| Host Interface | PCI Express 1.1 x1 |
| Data Transfer Rate | 800 MB/s; 400 MB/s |
| Total Number of FireWire/i.LINK Ports | 3 |
| Number of FireWire/i.LINK 800 Ports | 2 |
| Number of FireWire/i.LINK 400 Ports | 1 |
| Form Factor | Plug-in Card |
| Card Height | 4.7" |
| Card Width | 0.7" |
| Card Length | 3.3" |
| Card Weight (Approximate) | 1.70 oz |
| Package Weight | 0.50 lbs |
| Package Height | 1.60" |
| Package Width | 5.70" |
| Package Depth | 8.30" |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Warranty | 2-Year |
Package Contents & OS Compatibility
- 3 Port 2b 1a 1394 PCI Express FireWire Card Adapter
- 1 x FireWire cable
- 1 x Low Profile Bracket
- 1 x Software CD
- 1 x Instruction Manual
Operating Systems Supported: Windows 2000, XP, Vista, 7, 8, 8.1, 10, 11; Windows Server 2003, 2008 R2, 2012, 2016, 2019; macOS 10.6 Snow Leopard to 13.0 Ventura; Linux 3.5.x and up (LTS versions only). Platforms: PC, Mac, Linux.
Installation Guide for StarTech.com FireWire Card
Pro tip: Power off system and discharge static before handling; use anti-static wrist strap for embedded systems.
- Power down and unplug the computer.
- Install the card into a Mini PCI Express slot; attach low profile bracket if needed.
- Connect FireWire devices to the ports.
- Power on and install drivers from included Software CD or download.
- Verify in OS device manager.
Why Choose StarTech.com PEX1394B3
Reliable FireWire expansion for legacy devices in modern compact systems, with proven compatibility and robust build quality.
Add FireWire connectivity to your Mini PCIe system—Order the StarTech.com PEX1394B3 today!
Type: FireWire Adapter
MPN: PEX1394B3
Compatible Brand: StarTech.com
Country of Origin: Taiwan
Manufacturer Warranty: 2 Years
Compatible Port: Mini PCI Express
External Interfaces: FireWire 800
Number of Ports: 3 Ports
Form Factor: Mini PCI Express
Model: PEX1394B3
Item Height: 4.7"
Item Length: 3.3"
Item Width: 0.7"
Brand: Does not apply
UPC: 065030825139
