StarTech.com 1-Port PCIe RS-232 Serial Card 11050-PC-SERIAL-CARD
StarTech.com 1-Port PCIe RS-232 Serial Card 11050-PC-SERIAL-CARD
Low stock: 5 left
Save 16%
Couldn't load pickup availability
Free shipping across the continental US & free returns
Description
StarTech.com 1-Port PCIe RS-232 Serial Card 11050-PC-SERIAL-CARD
This is a StarTech.com PCIe Serial Card (model 11050-PC-SERIAL-CARD, D&H Item Number 11050PCSERILCRD) that adds RS-232 (DB9) serial communication support to desktop computers or Small Form Factor (SFF) systems. Featuring 16C1050 UART with 256-byte FIFO buffers for transmit/receive, it supports bi-directional speeds up to 921.6 Kbps and includes serial port LED status lights. UPC: 065030894777. Ideal for legacy serial devices in logistics, manufacturing, POS equipment, security systems, A/V installations, and more.
Key Features & Legacy Connectivity Benefits
- RS-232 DB9 Serial Port – Enables control and communication with serial peripherals, ensuring compatibility with older equipment.
- 16C1050 UART Controller – Provides reliable high-speed data transfer with 256-byte FIFO buffers to reduce CPU load.
- High-Speed Performance – Bi-directional data rates up to 921.6 Kbps for efficient serial connections.
- Low-Profile Design – Includes low-profile bracket for SFF systems; standard bracket also compatible.
- LED Status Indicators – Serial port lights for easy monitoring of activity and power.
- Broad OS Support – Compatible with Windows and Linux systems for versatile deployment.
- Environmental Compliance – RoHS and WEEE certified for eco-friendly operation.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | StarTech.com |
| Brand Name | StarTech.com |
| Manufacturer Part Number | 11050-PC-SERIAL-CARD |
| D&H Item Number | 11050PCSERILCRD |
| Product Name | PCIe Serial Card |
| Product Type | Serial Adapter |
| UPC | 065030894777 |
| Host Interface | PCI Express x1 |
| Platform Supported | PC, Linux |
| Number of Serial Ports (External) | 1 |
| UART | 16C1050 |
| FIFO Buffer | 256-byte (transmit/receive) |
| Data Transfer Speed | Up to 921.6 Kbps bi-directional |
| Form Factor | Plug-in Card |
| Card Height | Low-profile |
| Card Height | 0.7" |
| Card Width | 2.6" |
| Card Depth | 2.6" |
| Card Weight (Approximate) | 0 oz |
| Package Weight | 0.3 lbs / 0.30 lbs |
| Package Height | 1.6" / 1.60" |
| Package Width | 5.7" / 5.70" |
| Package Depth | 8.3" / 8.30" |
| Country of Origin | Taiwan / TAIWAN |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | 2 Year / 2-years by StarTech.com, including free lifetime 24/5 multi-lingual technical assistance |
Package Contents & Installation Overview
- PCIe Serial Card
- 1 x Low-Profile Bracket
- 1 x Quick-Start Guide
Pro tip: Install into an available PCI Express x1 slot; power off system first and follow standard PCIe card precautions for ESD protection. Use the included quick-start guide for driver installation on Windows or Linux.
Why Choose StarTech.com 11050-PC-SERIAL-CARD
Provides essential legacy serial connectivity with modern PCIe performance, backed by a 2-year warranty and lifetime technical support. Perfect for maintaining serial devices without system upgrades.
Add reliable RS-232 serial support—Order the StarTech.com 11050-PC-SERIAL-CARD today!
Type: Serial Adapter
MPN: 11050-PC-SERIAL-CARD
Compatible Brand: StarTech.com
Country of Origin: Taiwan
Manufacturer Warranty: 2 Years
Compatible Port: PCI Express x1
External Interfaces: Serial (RS-232)
Number of Ports: 1 Port
Model: 11050-PC-SERIAL-CARD
Brand: Does not apply
UPC: 065030894777
