Description
StarTech 2-Port 2.5Gbps PCI Express PoE Network Card, Dual Intel I225-V, PCIe 802.3af/at PoE+ Multi-Gigabit Ethernet NIC
This is a StarTech 2-Port 2.5Gbps PCI Express PoE Network Card featuring dual Intel I225-V chipsets with Intel vPro technology for enhanced performance and data integrity. This PCIe Ethernet NIC supports IEEE 802.3af/at PoE+ standards as Power Sourcing Equipment (PSE), delivering up to 30W PSE and 25.5W PD per port at 48V DC. MPN: PR22GIP-NETWORK-CARD; UPC: 065030903523. It enables NBASE-T (802.3bz) multi-gigabit speeds over existing CAT5e/CAT6 cabling, with variable options including 2.5Gbps, 1Gbps, 100Mbps, and 10Mbps for compatibility with new and legacy hardware.
Key Features & Power over Ethernet Capabilities
- Dual Intel I225-V Chipsets – Supports Intel vPro for remote management, PXE boot, WoL, VLAN tagging, 9K jumbo frames, and full-duplex operation.
- PoE+ PSE Support – IEEE 802.3af/at compliant; powers remote devices like IP cameras, wireless access points, access control, kiosks, and IP phones without separate injectors.
- Multi-Gigabit NBASE-T – Up to 2.5GBASE-T speeds on CAT5e or better cabling; ideal for data-intensive tasks like network sharing, FTP, backups, and streaming.
- PCIe 2.0 x2 Interface – Compatible with PCI Express x2 (or higher) slots; includes standard and low-profile brackets for desktops and small form factor systems/servers.
- Advanced Networking – Twisted pair RJ-45 ports; backward compatible with 1G/100/10Mbps networks.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | StarTech.com |
| Brand Name | StarTech.com |
| Manufacturer Part Number | PR22GIP-NETWORK-CARD |
| UPC | 065030903523 |
| Product Type | 2.5Gigabit Ethernet Card |
| Chipset Manufacturer | Intel |
| Chipset Model | I225-V (Dual) |
| Host Interface | PCI Express 2.0 x2 |
| Total Number of Ports | 2 |
| Number of Network (RJ-45) Ports | 2 |
| Media Type Supported | Twisted Pair |
| Maximum Data Transfer Rate | 2.50 Gbit/s |
| Network Technology | 2.5GBase-T |
| Form Factor | Plug-in Card |
| Bracket Height | Low Profile |
| Product Color | Black |
| Height | 0.8" |
| Width | 4.8" |
| Weight (Approximate) | 3.92 oz |
| PoE Standards | IEEE 802.3af/at (Type 1 & 2) |
| PoE Power Output | Up to 30W PSE, 25.5W PD per port at 48V DC |
| Features | Jumbo Frames (9K), PXE Boot, Wake on LAN (WoL), VLAN Tagging, Full-Duplex, Intel vPro, NBASE-T |
| Operating Humidity Range | 5% - 90% (Non-condensing) |
| Country of Origin | Malaysia |
| Environmental Compliance | RoHS, WEEE |
| Manufacturer Warranty | 2 Year |
Operating System & Application Compatibility
- Supported OS: Windows 10, Windows 11, Windows Server 2019, Windows Server 2022, Windows Server 2002, Linux 5.8, VMware ESXi 7.0
- Application/Usage: Network, Server, IP Camera, Wireless Access Point, Desktop, IP Phone
Package Contents
- 2.5Gigabit Ethernet Card
- 1 x Low Profile Bracket
- 1 x Quick-Start Guide
Upgrade your network with StarTech 2-Port 2.5Gbps PoE+ PCIe NIC—Order today!
Type: 2.5Gigabit Ethernet Card
Model: I225-V (Dual)
MPN: PR22GIP-NETWORK-CARD
Compatible Brand: StarTech.com
Country of Origin: Malaysia
Manufacturer Warranty: 2 Years
External Interfaces: RJ-45
Compatible Port: PCI Express
Number of Ports: 2 Ports
Item Height: 0.8"
Item Width: 4.8"
Brand: Does not apply
UPC: 065030903523
