Key Product Features

• Heavy-Duty Forged Construction – Manufactured from heat-treated, high-grade steel to resist snapping and twisting under high torque loads.
• Precision-Machined Splines – Features 24.5-inch precision splines designed for a perfect "zero-play" fit into the differential, reducing wear on internal gears.
• Enhanced Vibration Dampening – The upgraded metal composition helps absorb shocks from uneven terrain, providing superior stability and protecting your rear-end assembly.
• Direct OEM Replacement – Designed to be a "drop-in" fit for your RXV, matching multiple OEM part numbers for a frustration-free installation.
• Corrosion-Resistant Coating – Finished with a protective layer to prevent rust and degradation from grass, moisture, and fertilizers.

Technical Specifications

Compatibility & Fitment Notes

To ensure this part fits your cart, please verify the following:

• Model Check: This shaft is strictly for the Electric EZGO RXV. It will NOT fit Gas models or TXT/Marathon series.
• Side Specific: This is for the Driver Side (Left). If you need the passenger side, please check our other listings.
• Year Range: Fits all models from 2008 to the current production year.

Professional Installation Guide

Recommended steps for a successful replacement:

1. Safety Prep: Park on level ground and chock the front wheels. Disconnect the battery for safety.
2. Lift and Support: Jack up the rear of the cart and secure it with heavy-duty jack stands under the frame.
3. Wheel Removal: Use a lug wrench to remove the rear driver-side wheel.
4. Brake Hub Access: Remove the castle nut, cotter pin, and brake drum/hub assembly. Inspect your bearings and seals for wear while the axle is exposed.
5. Extracting the Axle: Remove the retaining C-clip (if applicable) and slide the old axle shaft out. Use an axle puller or slide hammer if the shaft is seized.
6. Installing the New Shaft: Thoroughly grease the splines of the new 24.5" Axle and slide it into the differential until you feel the gears engage.
7. Reassembly: Reinstall the retaining clip, hub, and brake components. Torque the axle nut to the manufacturer’s recommended foot-pounds and install a new cotter pin.
8. Test Drive: Lower the cart and perform a slow test drive to ensure quiet operation and smooth acceleration.

Why Upgrade Your Axle Now?

Golf cart axles are subject to extreme stress, especially on the electric RXV models with high-torque motors. Over time, the splines can round off, leading to a complete loss of drive. Our Upgraded Spline Axle Shaft is designed to be the last replacement you'll ever need. By choosing a high-strength metal variant, you are protecting your motor and differential from the damaging vibrations caused by worn-out factory shafts.
