NETGEAR M4250-40G8F-PoE+ AV Line Managed Switch
NETGEAR M4250-40G8F-PoE+ AV Line Managed Switch
Low stock: 5 left
Couldn't load pickup availability
Free shipping across the continental US & free returns
Description
Netgear M4250-40G8F-PoE+ AV Line Managed Switch
This is an Ethernet Switch manufactured by NETGEAR under the model M4250-40G8F-PoE+ AV Line Managed Switch. It is engineered for AV over IP applications with dedicated support for audio and video professionals, featuring 40 Gigabit Ethernet PoE+ ports and 8 SFP expansion slots.
Key Features of the Netgear M4250-40G8F-PoE+ AV Line Managed Switch
- AV Line Design – Pre-configured profiles for Dante, Q-SYS, AES67, NVX, AMX, NDI and mixed audio/video/control signals with color-based port assignment.
- PoE+ Support – 480 W PoE budget across 40 ports with rear-facing connectivity for clean AV rack integration.
- Layer 3 Capabilities – Includes static routing, RIP, PIM, DHCP server and PTPv2 along with IGMP Plus for automated multi-switch connectivity.
- AVB Ready – Optional AVB license support for low-latency audio transport in live performance environments.
- Management Options – Dedicated AV web GUI, standard IT CLI, SNMP, sFlow, RSPAN and NMS300 single-pane management.
- Flexible Mounting – 1U rack-mountable or tabletop with standard or recessed options and ports facing front or rear.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Brand | NETGEAR |
| Product Line | AV Line |
| Product Series | M4250 |
| Model | M4250-40G8F-PoE+ |
| Manufacturer Part Number | GSM4248P-100NAS |
| UPC | 606449151657 |
| Product Type | Ethernet Switch |
| Total Network Ports | 40 |
| Port Details | 40 x Gigabit Ethernet PoE+; 8 x Gigabit Ethernet Expansion Slot |
| Uplink Port | Yes |
| Modular | Yes |
| Expansion Slots | 8 x SFP (mini-GBIC) |
| Media Supported | Optical Fiber; Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T; 1000Base-X |
| Layer Supported | 3 |
| Manageable | Yes |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 480 W |
| Power Source | Power Supply |
| Number of Power Supplies | 1 |
| Power Consumption | 59.50 W |
| Plug/Connector Type | C14 |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable; Table Top |
| Height | 15.7" |
| Width | 17.3" |
| Depth | 1.7" |
| Weight | 12.90 lb |
| Country of Origin | Thailand |
| Environmentally Friendly | Yes |
Package Contents
- M4250-40G8F-PoE+ AV Line Managed Switch
- Power Cord(s)
- RJ45 Straight-through Wiring Serial Console Cable to DB9
- USB Type-C to USB-A 2.0 Console Cable
- Rubber Caps for the SFP/SFP+ Sockets
- Rubber Footpads for Tabletop Installation
- Installation Guide
- 2 x Regular (Short) Brackets and Screws for Two-post Rack Mount
- 2 x Longer Brackets for Two-post Rack Mount
Order the Netgear M4250-40G8F-PoE+ AV Line Managed Switch today.
Country of Origin: Thailand
UPC: 606449151657
Network Management Type: Fully Managed
MPN: GSM4248P-100NAS
Network Connectivity: Wired-Ethernet (RJ-45)
Network Type: ATA over Ethernet
Brand: NETGEAR
Maximum LAN Data Rate: 1000 Mbps/1 Gbps
Form Factor: Rack Mountable
Maximum Data Transfer Rate: 40 Gbps
Ethernet Technology: Gigabit Ethernet (1000-Mbit/s)
Layer: 2
Number of WAN Ports: 8
Type: Ethernet Switch
Model: NETGEAR M4250-40G8F-PoE+
Number of LAN Ports: 40
Interface: Ethernet (RJ-45)
Product Line: AV Line
