Description
Netgear Business GS752TXUPv3 Ethernet Switch
This is a Netgear Business GS752TXUPv3 Ethernet Switch. It is a 48-port Layer 3 managed Gigabit Ethernet switch with 4 dedicated 10G SFP+ uplinks, full PoE+ and PoE++ support, and remote or cloud management capability. The switch belongs to the NETGEAR Smart switches with Cloud family and supports high-density PoE device deployments in business environments such as hospitality, education, retail, and small offices.
Manufacturer: NETGEAR. Product Line: Business. Product Model: GS752TXUPv3. Manufacturer Item Number: GS752TXUP-300NAS. UPC: 606449173468. D&H Item Number: GS752TXUP300NAS.
Key Features
- 48 total network ports including 32 x 10/100/1000BASE-T Gigabit Ethernet PoE+ RJ-45 ports and 16 x 10/100/1000BASE-T Gigabit Ethernet PoE++ RJ-45 ports.
- 4 x 1000/10GBASE-X Gigabit Ethernet SFP+ expansion slots for uplink connectivity.
- PoE budget of 640 W with support for PoE+ and PoE++ devices such as wireless access points, IP cameras, VoIP phones, IoT devices, and security cameras.
- Layer 3 static routing for IPv4 and IPv6, LACP link aggregation, DiffServ QoS, Private VLANs, Multicast VLAN Registration, and Spanning Tree protocols.
- Configurable L2 features including VLANs, DHCP snooping, dynamic ARP inspection, access control lists, remote monitoring (RMON), and DHCP relay.
- Remote or cloud management, zero-touch provisioning (ZTP), energy efficient operation, and VLAN segmentation.
- Temperature- and load-based fan-speed control for minimized acoustic noise rated at a maximum of 37.3 dBA under full load at 25 degrees Celsius ambient.
- MTBF rating of 191643 hours. Power consumption of 763 W. Single power supply installed.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | NETGEAR |
| Brand Name | Netgear |
| Product Line | Business |
| Product Model | GS752TXUPv3 |
| Manufacturer Part Number | GS752TXUP-300NAS |
| UPC | 606449173468 |
| Product Type | Ethernet Switch |
| Total Number of Network Ports | 48 |
| Uplink Port | Yes |
| Network (RJ-45) | Yes |
| Port Details | 32 x 10/100/1000BASE-T Gigabit Ethernet PoE+ RJ-45; 16 x 10/100/1000BASE-T Gigabit Ethernet PoE++ RJ-45; 4 x 1000/10GBASE-X Gigabit Ethernet SFP+ |
| Total Expansion Slots | 4 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Media Supported | Optical Fiber; Twisted Pair |
| Ethernet Technology | Gigabit Ethernet; 10 Gigabit Ethernet |
| Network Technology | 10GBase-X; 10/100/1000Base-T; 1000Base-X |
| Maximum Data Transfer Rate | 1.25 GB/s |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1x; IEEE 802.1Q; IEEE 802.3ad; IEEE 802.3x; IEEE 802.1p; IEEE 802.3az; IEEE 802.11ac; IEEE 802.1D; IEEE 802.1w; IEEE 802.1s; IEEE 802.1ab; IEEE 802.3; IEEE 802.3u; IEEE 802.3ab; IEEE 802.3z; IEEE 802.3at; IEEE 802.3bt |
| Manageable | Yes |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 640 W |
| Power Source | Power Supply; PoE+; PoE++ |
| Number of Power Supplies Installed | 1 |
| Power Consumption | 763 W |
| MTBF | 191643 Hour |
| Form Factor | Rack-mountable; Desktop; Table Top |
| Height | 1.7" |
| Width | 17.3" |
| Depth | 12.4" |
| Weight (Approximate) | 10.56 lb |
| Application/Usage | Network; Wireless Access Point; IP Camera; IoT Devices; VoIP Phone; Business; Server; Security Camera; Security; Router; Surveillance; IP Phone; Small Business |
| Certifications & Standards | CE; FCC Class A; RCM; ICES Class A; VCCI; KC; BSMI; UKCA; CB; CSA |
Package Contents
- Business GS752TXUPv3 Ethernet Switch
- AC Power Cord With C13 Connector
- Brackets and Screws For Rack Mounting
- Rubber Footpads For Tabletop Installation
- Rubber Protection Caps
- Installation Guide
Brand: NETGEAR
Type: Ethernet Switch
Model: GS752TXUPv3
Form Factor: Rack Mountable
MPN: GS752TXUP-300NAS
Number of LAN Ports: 48
Interface: Ethernet (RJ-45)
Maximum Data Transfer Rate: 10 Gbps
Maximum LAN Data Rate: 10 Gbps
Network Connectivity: Wired-Ethernet (RJ-45)
Layer: 3
UPC: 606449173468
