MSI MAG 750W 80+ Gold Fully Modular ATX 3.1 PCIe 5.1 PSU
MSI MAG 750W 80+ Gold Fully Modular ATX 3.1 PCIe 5.1 PSU
Low stock: 5 left
Save 16%
Couldn't load pickup availability
Free shipping across the continental US & free returns
Description
MSI MAG 750W 80+ Gold Fully Modular ATX 3.1 PCIe 5.1 PSU
This is a MSI MAG 750W Power Supply, an internal ATX 3.1 compliant power supply unit delivering 750W with 80 Plus Gold efficiency certification. Featuring fully modular cabling, Active PFC, a single +12V rail, and PCIe 5.1 connector support, it includes a 135mm Fluid Dynamic Bearing fan for low noise operation described as Midnight Sound Level. MPN: MAGA750GLSPCIE5; UPC: 824142395820. Designed for quiet, reliable performance in modern PC builds.
Key Features of MSI MAG 750W Power Supply
- Fully Modular Design – All cables detachable for clean builds and optimal airflow.
- 80 Plus Gold Efficiency – Up to 90% efficiency at typical loads for reduced energy waste and heat.
- ATX 3.1 & PCIe 5.1 Compliance – Ready for next-gen GPUs with PCI Express 5.1 support.
- Single +12V Rail – 62.5A capacity for high-power components.
- Comprehensive Protections – Over Current, Over Temperature, Over Power, Short Circuit, Over Voltage, Under Voltage, Surge & Inrush, No Load.
- 135mm FDB Fan – Fluid Dynamic Bearing for smooth, quiet operation with low noise levels.
- On/Off Switch & Low Noise – Ensures serene computing experience free from disturbances.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | MSI |
| Brand Name | MSI |
| Product Series | MAG |
| Product Name | MAG 750W Power Supply |
| Manufacturer Part Number | MAGA750GLSPCIE5 |
| UPC | 824142395820 |
| Product Type | Power Supply |
| Form Factor | Internal |
| Specification Compliance | ATX 3.1 |
| Energy Efficiency Certification | 80 Plus Gold |
| Efficiency | 90% |
| Power Factor Correction (PFC) | Active |
| Number of +12V Rails | 1 |
| Output Power | 750 W |
| Input Voltage | 120 V AC, 230 V AC |
| Input Voltage Range | 100 V AC - 240 V AC |
| Input Frequency | 50-60 Hz |
| Output Voltage | 5 V DC, 3.3 V DC, 12 V DC, -12 V DC, 5 V SB |
| Output Voltage Detail | 5 V DC @ 20 A, 3.3 V DC @ 20 A, 12 V DC @ 62.5 A, -12 V DC @ 0.3 A, 5 V SB @ 3 A |
| Output Current | 20 A, 62.50 A, 300 mA, 3 A |
| Number of Fans | 1 |
| Fan Bearing Type | Fluid Dynamic Bearing |
| Fan Diameter | 135 mm |
| Modular | Yes |
| Modular Type | Fully Modular |
| PCI Express Connector | Yes |
| PCI Express Version | 5.1 |
| Number of SATA Power Connectors | 5 |
| Number of (6+2 pin) PCI Express Power Connectors | 4 |
| Number of (4+4 pin) CPU Power Connectors | 2 |
| Number of 4-pin Molex Power Connectors | 2 |
| Protection Type | Over Current, Over Temperature, Over Power, Short Circuit, Over Voltage, Under Voltage, Surge & Inrush Protection, No Load |
| Features | On/Off Switch, Low Noise |
| Physical Height | 3.4" |
| Physical Width | 5.9" |
| Physical Depth | 5.9" |
| Weight | 5.80 lbs |
| Country of Origin | VIET NAM |
| Manufacturer Warranty | 10 Year |
Installation & Maintenance Guide
Standard ATX PSU installation in compatible PC cases; power off system before proceeding.
- Power off and unplug PC; remove side panel.
- Mount PSU in case bay using screws; ensure fan faces intake or exhaust per case airflow.
- Connect modular cables: 24-pin ATX, CPU (4+4 pin), PCIe (6+2 pin), SATA, Molex as needed.
- Route cables neatly; secure with ties.
- Test power-on; monitor for stability.
- Maintenance: Dust fan periodically with compressed air; operate in well-ventilated area.
Why Choose MSI MAG 750W PSU
Provides reliable power delivery with extensive protections, fully modular flexibility, and 10-year warranty for long-term PC stability.
Power your build with MSI MAG 750W—add to cart now!
Brand: MSI
Type: Power Supply
Color: Black
Features: Modular
Model: MAG A750GL PCIe5
MPN: MAGA750GLSPCIE5
Manufacturer Warranty: 10 Years
Maximum Power: 750 W
Connectors: 24 Pin
Voltage Compatibility: 120 V
Form Factor: ATX
Cooling: 1 Fan
Item Height: 3.4"
Item Width: 5.9"
Item Length: 5.9"
UPC: 824142395820
