Intel RT3EX020E RAID Controller PCIe 2.0 x2 2-Port SATA
Intel RT3EX020E RAID Controller PCIe 2.0 x2 2-Port SATA
Low stock: 3 left
Save 16%
Couldn't load pickup availability
Free shipping across the continental US & free returns
Description
Intel RT3EX020E RAID Controller PCIe 2.0 x2 2-Port SATA
This is a SATA Controller designed as a plug-in RAID card for servers, the Intel RAID Controller RT3EX020E. It provides Serial ATA connectivity with RAID level 1 support via a PCI Express 2.0 x2 host interface and 2 internal SATA ports. MPN: RT3EX020E; UPC: 735858487160. Compatible with PC and Linux platforms for server environments.
Key Features of Intel RT3EX020E RAID Controller
- PCI Express 2.0 x2 Host Interface – Ensures reliable high-speed data transfer for server storage needs.
- Serial ATA Controller – Supports standard SATA drives with integrated RAID functionality.
- RAID Level 1 – Enables data mirroring for redundancy in server applications.
- 2 Internal SATA Ports – Provides direct connectivity for up to two SATA drives.
- Plug-in Card Form Factor – Easy installation into compatible server PCIe slots.
- Server Device Support – Optimized for server-grade performance and reliability.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Intel Corporation |
| Brand Name | Intel |
| Product Model | RT3EX020E |
| Product Name | RAID Controller RT3EX020E |
| Product Type | SATA Controller |
| MPN | RT3EX020E |
| UPC | 735858487160 |
| Host Interface | PCI Express 2.0 x2 |
| Controller Type | Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 1 |
| Device Supported | Server |
| Total Number of SATA Ports | 2 |
| Number of SATA Ports (Internal) | 2 |
| Form Factor | Plug-in Card |
| Platform Supported | PC, Linux |
| Operating System Supported | CentOS, Windows Server 2016, Windows Server 2019, Red Hat Enterprise Linux 8.2, SUSE Linux Enterprise Server 15 SP1 |
| Weight | 0.80 |
| Height | 3.70 |
| Width | 11.90 |
| Depth | 8.60 |
Server Storage Enhancement with Intel RT3EX020E
The Intel RT3EX020E delivers essential RAID 1 mirroring for data protection in supported server configurations, leveraging Intel engineering for Serial ATA performance on PCI Express infrastructure.
Add reliable SATA RAID to your server—Order Intel RT3EX020E today!
Brand: Intel
MPN: RT3EX020E
Compatible Brand: For Intel
Item Height: 3.70
Item Length: 8.60
Item Width: 11.90
UPC: 735858487160
