HPE Instant On 1430 16G Class4 PoE 124W Switch
HPE Instant On 1430 16G Class4 PoE 124W Switch
Low stock: 5 left
Save 24%
Couldn't load pickup availability
Free shipping across the continental US & free returns
Description
HPE Instant On 1430 16G Class4 PoE 124W Switch
This is a HPE Instant On 1430 16G Class4 PoE 124W Switch, a plug-and-play unmanaged Layer 2 Gigabit Ethernet switch from the Aruba Instant On 1430 Switch Series. Designed for small businesses, home offices, and SMBs, it provides reliable, low-cost network connectivity with 16 Gigabit PoE ports and a 124W PoE budget supporting Class 4 devices like access points, surveillance cameras, and VoIP phones. Manufacturer Part Number: R8R48A#ABA; UPC: 190017602196. Fanless operation ensures silent performance in acoustically sensitive areas, with zero ongoing maintenance required.
Key Features of HPE Instant On 1430 16G Class4 PoE 124W Switch
- 16 x Gigabit Ethernet PoE Ports – Delivers Layer 2 switching for printers, access points, and shared resources without configuration.
- 124W PoE Budget – Supports up to 30W per port for Class 4 PoE devices, powering the latest IoT endpoints.
- Fanless Design – Ideal for quiet environments like offices and home setups.
- Plug-and-Play Operation – Fully automated functions; unmanaged with no IT expertise needed.
- Versatile Mounting – Rack-mountable (1U), wall mountable, table top, cabinet mount, surface mount, or under table.
- Comprehensive Standards Support – IEEE 802.1x, 802.1p, 802.3, 802.3u, 802.3ab, 802.3i, 802.3z, 802.3af, 802.3at, 802.3x, 802.3az for robust connectivity.
- Twisted Pair Media – 10/100/1000Base-T network technology for high-speed performance.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Brand Name | HPE |
| Product Line | Instant On |
| Product Series | 1430 |
| Product Name | Instant On 1430 16G Class4 PoE 124W Switch |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | R8R48A#ABA |
| UPC | 190017602196 |
| Total Number of Network Ports | 16 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 16 x Gigabit Ethernet PoE |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.1x, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.3az |
| Manageable | No |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 124 W |
| Input Voltage | 120 V AC, 230 V AC |
| Frequency | 50 Hz, 60 Hz |
| Power Source | Power Supply |
| Power Consumption | 147 W |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable, Cabinet Mount, Table Top, Wall Mountable, Surface Mount, Under Table |
| Height | 1.7" |
| Width | 10.8" |
| Depth | 10.2" |
| Weight (Approximate) | 4.60 lb |
| Features | Fanless |
| Application/Usage | Business |
Package Contents and Additional Information
- Instant On 1430 16G Class4 PoE 124W Switch
- 2-post Rack Kit Brackets
Limited warranty includes 24 x 7 chat support for the entire warranty period. Part of the Aruba Instant On 1430 Switch Series offering PoE and non-PoE models from 5 to 26 ports.
Why Choose HPE Instant On 1430 Switch
Provides simple, reliable Gigabit connectivity for small offices without IT support, enabling fast setup for resource sharing and IoT device powering in budget-conscious environments.
Enhance your network with the HPE Instant On 1430 16G Class4 PoE 124W Switch—Order now!
Brand: HPE
Type: Ethernet Switch
Model: 1430
MPN: R8R48A
Number of LAN Ports: 16
Ethernet Technology: Gigabit Ethernet (1000-Mbit/s)
Interface: Ethernet (RJ-45)
Network Management Type: Unmanaged
Maximum Data Transfer Rate: 1 Gbps
Form Factor: Rack Mountable
Maximum LAN Data Rate: 1000 Mbps/1 Gbps
Network Connectivity: Wired-Ethernet (RJ-45)
Layer: 2
UPC: 190017602196
