HPE Aruba 6100 12G CL4 2SFP+ Ethernet Switch JL679A
HPE Aruba 6100 12G CL4 2SFP+ Ethernet Switch JL679A
Low stock: 5 left
Couldn't load pickup availability
Free shipping across the continental US & free returns
Description
HPE Aruba 6100 12G CL4 2SFP+ Ethernet Switch JL679A
This is an Ethernet Switch from the Aruba CX 6100 Switch Series. The HPE 6100 Ethernet Switch model 6100 12G CL4 2SFP+ delivers entry-level Layer 2 access switching for enterprise branch offices and SMB networks with support for IoT, mobile, and cloud applications. It uses the Aruba ASIC architecture and programmable AOS-CX operating system for consistent operation across the Aruba CX portfolio.
Key Features of HPE 6100 Ethernet Switch
- AOS-CX Operating System – Database-driven modular Linux architecture with REST APIs, micro-services, and near real-time state synchronization.
- Aruba ASIC Architecture – Programmable hardware providing low latency, increased packet buffering, and adaptive power consumption.
- High-Speed Uplinks – Two 10 Gigabit Ethernet SFP+ slots and two Gigabit Ethernet uplinks for flexible connectivity.
- PoE Support – 12 x Gigabit Ethernet PoE ports with 139 W PoE budget for security cameras and wireless access points.
- Performance Metrics – Up to 176 Gbps non-blocking bandwidth and up to 98.6 Mpps forwarding rate with selectable queue configurations.
- Management Capabilities – Fully manageable with support for static routing, robust QoS, and IPv6; no software licensing required.
- Compact Form Factor – 1U rack-mountable, wall-mountable, or surface-mount design suitable for quiet workspaces.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Brand | HPE ARUBA |
| Manufacturer | Hewlett Packard Enterprise |
| Product Series | 6100 |
| Product Model | 6100 12G CL4 2SFP+ |
| MPN | JL679A#ABA |
| UPC | 190017348957 |
| Product Type | Ethernet Switch |
| Layer Supported | 2 |
| Total Network Ports | 12 |
| Port Details | 12 x Gigabit Ethernet PoE, 2 x 10 Gigabit Ethernet Expansion Slot, 2 x Gigabit Ethernet Uplink |
| Expansion Slots | 2 x SFP+ |
| Media Supported | Optical Fiber, Twisted Pair |
| Ethernet Technology | Gigabit Ethernet, 10 Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T, 10GBase-X |
| PoE Budget | 139 W |
| Power Consumption | 21.90 W |
| Power Source | Power Supply |
| Number of Power Supplies | 1 |
| Frequency | 50 Hz / 60 Hz |
| Bandwidth | Up to 176 Gbps non-blocking |
| Forwarding Rate | Up to 98.6 Mpps |
| Form Factor | 1U, Wall Mountable, Rack-mountable, Surface Mount |
| Dimensions (Device) | 1.7" H x 10" W x 10" D |
| Weight (Approximate) | 6.13 lb |
| Manageable | Yes |
| Environmental Compliance | RoHS, WEEE |
| Environmentally Friendly | Yes |
Additional Product Details
The HPE 6100 Ethernet Switch includes built-in high-speed uplinks, support for up to 370 W PoE on the series, and a fanless compact model option. It provides centralized configuration validation, automated deployment, and integration with Aruba NetEdit for network-wide policy conformance. The switch supports IoT device connectivity while simplifying ownership through the absence of software licensing requirements.
Model: 6100 12G CL4 2SFP+
Maximum LAN Data Rate: 10 Gbps
UPC: 190017348957
Network Management Type: Fully Managed
MPN: JL679A
Item Length: 1.73 in
Item Height: 7.92 in
Item Width: 17.4 in
Network Connectivity: Wired-Ethernet (RJ-45)
Brand: HPE
Form Factor: Rack Mountable
Ethernet Technology: Gigabit Ethernet (1000-Mbit/s)
Layer: 2
Type: Ethernet Switch
Number of LAN Ports: 16
Interface: Ethernet (RJ-45)
Product Line: Enterprise
