HPE AP-534 3.55 Gbit/s 802.11ac Wireless Access Point TAA Compliant
HPE AP-534 3.55 Gbit/s 802.11ac Wireless Access Point TAA Compliant
Low stock: 5 left
Couldn't load pickup availability
Free shipping across the continental US & free returns
Description
HPE AP-534 IEEE 802.11ac 3.55 Gbit/s Wireless Access Point - TAA Compliant
This is a Wireless Access Point from the Aruba 530 Series designed for high-density environments. The HPE AP-534 IEEE 802.11ac 3.55 Gbit/s Wireless Access Point - TAA Compliant delivers 802.11ax performance with support for OFDMA, MU-MIMO, and 1024-QAM modulation while remaining TAA Compliant.
Key Features of HPE AP-534 IEEE 802.11ac 3.55 Gbit/s Wireless Access Point - TAA Compliant
- 802.11ax Technology – Supports up- and downlink OFDMA with up to 37 resource units and multi-user MIMO for simultaneous client service.
- Dual-Band Operation – 2.40 GHz and 5 GHz bands with 4x4 MIMO and up to four spatial streams per band.
- Peak Data Rate – 2.4 Gbps on 5 GHz and 1,150 Mbps on 2.4 GHz for an aggregate of 3.55 Gbit/s.
- Client Capacity – Supports up to 1024 associated client devices per radio.
- Additional Radios – Includes Bluetooth 5 and radios for location services and IoT applications.
- Aruba ClientMatch – Automatically groups 802.11ax devices to maximize OFDMA performance.
- Mounting Options – Wall Mountable, Ceiling Mountable, Rail-mountable form factor.
- Power and Connectivity – 5 Gigabit Ethernet ports, PoE PD support, and USB port.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Brand | HPE ARUBA |
| Manufacturer | Hewlett Packard Enterprise |
| Product Series | 530 |
| Product Model | AP-534 |
| MPN | JZ332A |
| UPC | 190017232713 |
| Wireless LAN Standard | IEEE 802.11ac |
| Bluetooth Standard | Bluetooth 5 |
| Frequency Band | 2.40 GHz, 5 GHz |
| Wireless Transmission Speed | 3.55 Gbit/s |
| MIMO Technology | Yes |
| Beamforming Technology | Yes |
| Ethernet Technology | 5 Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 2 |
| PoE PD Port | Yes |
| USB | Yes |
| Form Factor | Wall Mountable, Ceiling Mountable, Rail-mountable |
| Height | 2.2" |
| Width | 9.4" |
| Depth | 9.4" |
| Weight (Approximate) | 2.20 lb |
| Country of Origin | UNITED STATES |
| TAA Compliant | Yes |
| Product Type | Wireless Access Point |
Performance Enhancements in HPE AP-534 IEEE 802.11ac 3.55 Gbit/s Wireless Access Point - TAA Compliant
The 530 Series uses Orthogonal Frequency Division Multiple Access (OFDMA) to increase user data rates and reduce latency for voice and IoT devices. Multi-user MIMO allows multiple devices to transmit simultaneously. Optional tri-radio mode splits the 5 GHz radio into two independent 4x4 MIMO radios. Channel bandwidths reach 160 MHz in 5 GHz and 40 MHz in 2.4 GHz with 1024-QAM modulation.
HPE AP-534 IEEE 802.11ac 3.55 Gbit/s Wireless Access Point - TAA Compliant
MPN: JZ332A
Brand: HPE ARUBA
Model: AP-534
Unit Type: Unit
Country of Origin: United States
UPC: 190017232713
