Key Performance Features

• Integrated ABS Technology – Includes a factory-calibrated ABS sensor and tone ring to maintain precise braking control and safety.
• Advanced Seal Design – Multi-lip internal seals protect the precision-ground bearings from water, mud, and road salt, significantly extending service life.
• Pre-Greased & Maintenance Free – Internal ball bearings are packed with high-temperature premium grease to reduce friction and heat buildup during heavy towing.
• OE-Spec Precision – Manufactured in ISO-certified facilities to ensure an exact "bolt-on" fit without any modifications to the steering knuckle or CV axle.
• Vibration-Free Operation – Rigorously tested to eliminate the grinding, humming, and steering wheel play common in worn factory hubs.

Technical Specifications

Professional Installation Tips

Follow these steps for a secure and long-lasting repair:

1. Safety: Jack up the vehicle and use high-capacity jack stands. Remove the wheel and brake assembly.
2. ABS Harness: Carefully unclip the old ABS wire from the frame before removing the hub to avoid damaging the vehicle's wiring.
3. Axle Nut: Remove the CV axle nut. Ensure the axle splines are clean and lubricated before installing the new hub.
4. Torque Specs: Critical: Torque the hub-to-knuckle bolts to 150-160 ft-lbs and the main CV axle nut to approximately 20 ft-lbs (refer to your specific service manual).
5. Post-Install: Pump the brakes several times before driving to reset the caliper pistons.

Why Upgrade Your Hub?

A failing wheel bearing isn't just noisy—it's a major safety risk that can lead to wheel lock-up or detachment. Our Premium Hub Assembly is designed for the high torque and heavy loads of the F-150 platform. Whether you use your truck for daily commuting, heavy towing, or weekend off-roading, this hub provides the reliability you need to keep your truck on the road and out of the shop.
