Description
Eaton Tripp Lite Series 550VA 300W Standby UPS - 10 NEMA 5-15R Outlets, 120V, 50/60 Hz, USB, 5-15P Plug, Desktop/Wall Mount
This is a Standby UPS from Eaton that provides battery-supported AC output during brownouts and blackouts. The unit supports entry-level PCs for up to 17 minutes during power failures and includes an HID-compliant USB interface for integration with Windows and Mac OS X power management features.
The Eaton Tripp Lite INTERNET550U model delivers 550VA/300W capacity with 10 NEMA 5-15R outlets. Five outlets provide full battery support and surge suppression while five outlets provide surge suppression only. Single-line telephone suppression protects connected peripherals.
Key Features
- Standby protection prevents data loss and system downtime during brownouts and blackouts.
- Two widely spaced receptacles accommodate large transformer plugs.
- Four battery-supported outlets protect computers, monitors and vital components.
- Four surge-only outlets suit printers and accessories not requiring battery backup.
- RJ-11 and RJ-45 jacks provide dataline protection for modem or DSL connections.
- EMI/RFI noise filter and greater than 95 percent efficiency GREEN UPS operation.
- Audible alarm and front panel LED status indicators report line and battery s.
- Energy Star with PowerAlert software included.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Eaton Corporation |
| Brand Name | Tripp Lite series |
| Product Line | Internet Office |
| Product Model | INTERNET550U |
| Manufacturer Part Number | INTERNET550U |
| UPC | 037332211026 |
| Product Type | Standby UPS |
| Load Capacity (VA) | 550 VA |
| Load Capacity (Watt) | 300 W |
| Input Voltage | 120 V AC |
| Input Current | 12 A |
| Output Voltage | 110 V AC, 115 V AC, 120 V AC |
| Output Frequency | 60 Hz |
| Waveform Type | Pure Sine Wave |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 10 x NEMA 5-15R |
| Number of Battery & Surge Outlets | 5 |
| Number of Surge-only Outlets | 5 |
| Dataline Protection | RJ-11, RJ-45 |
| Protection Type | Black Out, Brownout, Surge, Line Noise, Over Voltage |
| Cord Length | 5 ft |
| Transfer Time | 6 ms |
| EMI/RFI Noise Filter | Yes |
| Surge Energy Rating | 316 J |
| DC System Voltage | 12 V DC |
| Backup/Run Time (Full Load) | 1.20 Minute |
| Backup/Run Time (Half Load) | 5 Minute |
| Typical Battery Recharge Time | 6.50 Hour |
| Replaceable Battery | Yes |
| Form Factor | Ultra-compact Desktop/Tower/Wall Mount |
| Height | 4.1 in |
| Width | 4.3 in |
| Depth | 7.3 in |
| Weight (Approximate) | 3.97 lb |
| Status Indicators | 1 x Status LED reports operating mode and fault status |
| Interfaces/Ports | USB (HID Compliant) Port: Yes |
| Application/Usage | Home/Office, Media Center, Commercial, Computer, Router, Printer, Storage Device, TV, Blu-ray Player, Gaming Console, Media Player, DVR, Audio System |
| Certifications & Standards | Energy Star |
| Software Included | PowerAlert Software |
| Country of Origin | Vietnam |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Packaged Quantity | 1 Each |
Package Contents
- Internet Office INTERNET550U 550VA UPS
- USB cable
- Owner's Manual
Brand: Tripp Lite
Type: Standby UPS
Color: Black
MPN: INTERNET550U
Compatible Model: INTERNET550U
Features: Audible Alarm
Model: INTERNET550U
Form Factor: Ultra-compact Desktop/Tower/Wall Mount
Voltage Compatibility: 110 V
Maximum Power: 300 W
Number of Outlets: 10
Country of Origin: Vietnam
Maximum Wattage: 300 W
Item Height: 4.1 in
Item Length: 7.3 in
Item Width: 4.3 in
UPC: 037332211026
