Vaddio EasyIP CeilingMIC D Microphone - For Conference Rooms - White

This is a Vaddio EasyIP CeilingMIC D Microphone designed for conference rooms. The unit is manufactured by Vaddio under Legrand Group and carries manufacturer item number 999-85810-000 along with UPC 840077506537. It belongs to the EasyIP CeilingMIC D product line and functions as a ceiling-mounted microphone with wired connectivity.

The microphone delivers full 360-degree pickup coverage through three unidirectional cardioid elements housed in a single pendant enclosure. Each element includes integrated echo cancellation and digital signal processing with equalization, filtering, and automatic gain control. The DSP receives its AEC reference from the far end for clear conference calls. Installation uses a single Cat-5e cable carrying power, control, and audio via PoE. The pendant includes a 3 ft adjustable drop cable that extends to 15 ft total length using a standard RJ45 jack. Central management occurs through free Dante Controller software, and DSP configuration uses Vaddio desktop tools. The design suits drop tile ceilings and open-ceiling environments while eliminating table clutter.

Key Features

• 360-degree pickup coverage from three microphone elements in one pendant
• Uni-directional cardioid polar pattern per element
• Integrated echo cancellation and DSP per element including equalization, filtering, and AGC
• Plug-and-play connection via single Cat-5e cable with PoE
• Adjustable 3 ft drop cable extendable to 15 ft total
• Compatible with Dante Controller software for routing and configuration
• Sleek design with acoustical fabric wrap for interior integration
• Ideal for average meeting room tables or larger spaces with multiple units

Comprehensive Technical Specifications

Package Contents

• EasyIP CeilingMIC D Microphone
• Silicone Split Strain Relief Boot
• 3 ft (0.9 m) Cat-5 Cable
• EasyIP CeilingMIC D Interface Box
• Cable Clamp Grommet
• 2 x Ceiling Trim Ring Plates with Mounting Screws
• Ceiling Tile Brace
• Installation Guide
