Description
Dell Pro Dock WD25 USB-C Docking Station
This is a Dell Pro Dock WD25 USB-C docking station designed for enhanced productivity in AI PC workplaces. The Dell Pro Dock WD25 offers powerful compatibility with up to 100W power delivery to Dell AI PCs and non-Dell systems, native support for up to four high-resolution displays, and advanced ports for USB and network connectivity. Manufacturer Part Number: DELL-WD25; UPC: 884116493662.
Key Features of Dell Pro Dock WD25
- Powerful Compatibility – Delivers up to 100W to Dell systems and 96W to non-Dell PCs; supports desktop PCs and notebooks.
- Upgraded for Modern Work – Native support for up to four displays including 6K@60Hz single, 5K@60Hz dual, 4K@60Hz single, QHD@60Hz dual, and more.
- Modern Manageability – Features MAC Address Pass-Through, PXE Boot, Dock Power Button Sync, Wake-on-LAN, WLAN to LAN Switch, Kernel DMA Protection, Dell Command Update, Port Disablement.
- Sustainable Innovation – Up to 72% reduction in standby power consumption; built with at least 65% post-consumer recycled materials; 100% recycled or renewable packaging.
- Thoughtful Design – Ambidextrous 2.95 ft USB-C cable routable left or right; robust USB-C connector for durability; LED power indicator.
- Elevate IT Efficiency – Centralize management via Dell Device Management Console; single firmware file updates; silent updates on disconnection.
- Advanced Connectivity – 2.5 Gigabit Ethernet; maximum data transfer rate 1.25 GB/s; Kensington Security Slot.
- Power Delivery Ports – 4x USB-A 3.2 Gen 2 (4.5W each), 1x USB-C 3.2 Gen 2 (15W), 1x USB-C Multi-function DisplayPort (7.5W); power with or without PC connected.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Dell Technologies / Dell Commercial |
| Brand Name | Dell |
| Product Line | Pro Dock |
| Product Model | WD25 |
| Product Name | Pro Dock WD25 |
| Product Type | Docking Station |
| Manufacturer Part Number | DELL-WD25 |
| UPC | 884116493662 |
| Connectivity Technology | Wired |
| Host Interface | USB Type C |
| Cable Length | 2.95 ft |
| Device Supported | Desktop PC, Notebook |
| Charging Capability | Yes |
| Number of Displays Supported | 4 |
| Screen Modes Supported | 5K @ 60Hz, 6K @ 60Hz, 4K @ 60Hz, QHD @ 60Hz, SXGA, FHD @ 60Hz, WQHD @ 60Hz |
| Supported Resolutions | 3440 x 1440, 5120 x 2160, 6144 x 3456, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024 |
| Video Resolution Details | SXGA - 60 Hz (Quad), FHD - 60 Hz (Triple), QHD - 60 Hz (Dual), 4K - 60 Hz (Single), WQHD - 60 Hz (Quad/Triple), 5K - 60 Hz (Dual), 6K - 60 Hz (Single) |
| Maximum Data Transfer Rate | 1.25 GB/s |
| Total Number of USB Ports | 6 |
| Number of USB Type-A Ports | 4 |
| Number of USB 3.2 Gen 2 Type-A Ports | 4 |
| Number of USB Type-C Ports | 2 |
| USB Type-C Detail | 1 x USB-C 3.2 Gen 2 (15W), 1 x USB-C Multi-function DisplayPort (7.5W) |
| Number of DisplayPorts | 2 |
| DisplayPort Version | 1.4 |
| Number of HDMI Ports | 1 |
| HDMI Version | 2.1 |
| Network (RJ-45) | Yes |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Power Delivery | 96W (non-Dell Systems), 100W (Dell Systems) |
| Power Delivery Details | 4 x USB-A 3.2 Gen 2 (4.5W each), 1 x USB-C 3.2 Gen 2 (15W), 1 x USB-C Multi-function DisplayPort (7.5W); All deliver power with or without PC |
| Maximum Power Supply Wattage | 130 W |
| Power Source Type | Power Adapter |
| Height (Product) | 8.07" |
| Width (Product) | 3.54" |
| Depth (Product) | 1.39" |
| Weight (Approximate, Product) | 1.21 lb |
| Weight (Shipping) | 3.10 lb |
| Height (Shipping) | 2.80" |
| Width (Shipping) | 9.50" |
| Depth (Shipping) | 11.50" |
| Security Slot Type | Kensington Security Slot |
| Post-consumer-waste% | 65% |
| Operating System Supported | Windows 10, Windows 11, ChromeOS 137, Ubuntu 24.04, Red Hat Enterprise Linux 9.6 |
Why Choose Dell Pro Dock WD25
The Dell Pro Dock WD25 provides flexible management capabilities as part of the most manageable commercial docking family, with universally compatible features like MAC Address Pass-Through and Power Button Sync for cross-brand docking experiences. It simplifies IT efficiency through cloud-based console management and streamlined firmware updates.
Enhance your workspace with the Dell Pro Dock WD25—Order now!
Brand: Dell
Type: Docking Station
Color: Black
Model: WD25
Compatible Model: WD25
MPN: DELL-WD25
Compatible Brand: Dell Commercial
Ports: DisplayPort
Item Height: 8.07 in
Item Width: 3.54 in
Item Length: 1.39 in
UPC: 884116493662
