C2G Cat5e Snagless Unshielded UTP Ethernet Patch Cable, RJ45 M/M, 7ft, Blue
C2G Cat5e Snagless Unshielded UTP Ethernet Patch Cable, RJ45 M/M, 7ft, Blue
Low stock: 5 left
Couldn't load pickup availability
Free shipping across the continental US & free returns
Description
C2G 7ft Cat5e Snagless Unshielded UTP Ethernet Patch Cable (RJ45 M/M), Blue
This is a C2G 7ft Cat5e Snagless Unshielded UTP Ethernet Network Patch Cable (RJ45 M/M) in blue with standard RJ45 connectors and 5600pF/100m capacitance. Designed for fast Ethernet networks supporting bandwidth-intensive voice, data, or video applications, it meets all Cat5e TIA/EIA standards. MPN: 15193; UPC: 757120151937. Constructed from high-quality copper with a snagless molded boot for easy installation and strain relief.
Key Features of C2G Cat5e Snagless Ethernet Patch Cable
- Snagless Design – Molded boot prevents cable snags during installation and provides extra strain relief.
- Bonded Pairs – Individual pairs bonded together to maintain twist-spacing up to the termination point, reducing impedance and structural return loss (SRL).
- High-Quality Copper Conductors – Minimizes Near-End Crosstalk (NEXT) levels for reliable performance.
- Unshielded Twisted Pair (UTP) – Category 5e construction supports fast Ethernet up to 1000 BASE-T.
- PVC Jacket – Durable blue color for easy network color-coding.
- Retail Packaging – Ready for immediate network deployment.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Brand | C2G |
| Manufacturer | Legrand Group |
| MPN | 15193 |
| UPC | 757120151937 |
| Cable Length | 7 ft |
| Cable Type | Category 5e, Unshielded Twisted Pair (UTP) |
| Cable Characteristic | Patch Cable |
| Connector Type (Both Ends) | RJ-45 Network - Male (1 x RJ-45 Male) |
| Conductor | Copper |
| Capacitance | 5600 pF/100m |
| Product Color | Blue |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Weight (Approximate) | 0.18 lb |
| Package Weight | 0.20 lb |
| Package Dimensions | Height: 0.20 in, Width: 6.80 in, Depth: 8.00 in |
| Certifications & Standards | TIA/EIA 568B, UL Listed |
| Country of Origin | China |
Supported Applications and Compatibility
- Network Standards: 1000 BASE-T, 100 BASE-T, 10 BASE-T (IEEE 802.3); 4/16 Mbps Token Ring (IEEE 802.5); 100 VG-AnyLAN; 100 Mbps TP-PMD (ANSI X3T9.5); 55/155 Mbps ATM; Voice.
- Device Compatibility: Hub, Switch, Router, Network Adapter, Modem, DSL/Cable, Patch Panel, and other twisted pair applications.
Installation and Maintenance
Plug-and-play installation: Connect RJ45 ends to compatible Ethernet ports. Pro tip: Route cable away from power lines to minimize interference; use snagless boot for secure, damage-free handling.
- Inspect ends for damage before use.
- Align and insert connectors firmly until clicked.
- Test connection with network diagnostics.
- Clean with mild soap if needed; avoid harsh chemicals on PVC jacket.
Enhance your Ethernet network connectivity—Order the C2G 7ft Cat5e patch cable today!
Brand: C2G
MPN: 15193
Color: Blue
Country of Origin: China
Compatible Brand: C2G
Connector A: Ethernet (RJ-45) Male
Cable Length: 7 ft
Connector B: Ethernet (RJ-45) Male
Type: Does not apply
UPC: 757120151937
